KR QUANTEC extra
8.2 Control cable for single axis (optional)
Description The control cable for single axis is used when additional axes (e.g. KUKA lin-
ear unit or turntables) are controlled via the robot. In this case, the control ca-
ble is guided from the RDC box through the hollow shaft of axis 1 to a
connector interface on the push-in module.
8.3 Release device (optional)
Description The release device can be used to move the manipulator manually after an ac-
cident or malfunction. The release device can be used for the motors of axes
1 to 5. It cannot be used for axis 6, as this motor is not accessible. It is only for
use in exceptional circumstances and emergencies (e.g. for freeing people).
The release device is mounted on the base frame of the manipulator. This as-
sembly also includes a ratchet and a set of plates with one plate for each mo-
tor. The plate specifies the direction of rotation for the ratchet and shows the
corresponding direction of motion of the manipulator.
