40 / 127 Issued: 18.06.2015 Version: Spez KR QUANTEC extra V6
KR QUANTEC extra
Fig. 4-21: Location of plates and labels
1 Plate “Hot surface”
2 Plate “High voltage”
3 Plate “Secure the axes”
4 Identification plate
5 Plate “Danger zone”
6 Plate “Transport position”
7 Plate “Mounting flange on in-line wrist”
8 Plate “Counterbalancing system”
9 Plate “Work on the robot”
Plate or label Description
1
Hot surface
During operation of the robot, surface
temperatures may be reached that could
result in burn injuries. Protective gloves
must be worn.
3
High voltage
Any improper handling can lead to con-
tact with current-carrying components.
Electric shock hazard!
3
Secure the axes
Before exchanging any motor, secure
the corresponding axis through safe-
guarding by suitable means/devices to
protect against possible movement. The
axis can move. Risk of crushing!
4
Identification plate
Content according to Machinery Direc-
tive.
