6-32
Program Mode and the Program Editor
The COMMON Page
When a stereo keymap layer uses a double-output algorithm, both keymaps are split between
the upper and lower wires. In other words, both wires carry the signal from each of the
keymaps. The Output Group (Pair), Output mode, and Gain level of Keymap 1 are mimicked by
Keymap 2 (that’s why these parameters aren’t displayed for Keymap 2 on the OUTPUT page).
You can, however, set the pan positions independently for the upper and lower wires of both
keymaps.
EditProg:OUTPUT||||||||||||<>Layer:1/1||
|||Pair:||Pan:||||||||||||||Mode:|Gain:|
U1:KDFX-A|L|||||||*|||||||R|Fixed|12dB||
L1:KDFX-A|L|||||||*|||||||R|+MIDI|12dB||
U2:|||||||L|||||||*|||||||R|||||||||||||
L2:|||||||L|||||||*|||||||R|||||||||||||
CrossFade|:OFF||||||XFadeSense:Norm|||||
<more||OUTPUT||||||||COMMON|SetRng|more>
The COMMON Page
Here’s where you find eight frequently-used parameters that affect the entire current program,
not just the current layer. The COMMON page is reached by pressing the COMMON soft
button in the Program Editor.
EditProg:COMMON||||||||||||||All|Layers|
Pitch|Bend|Range:200ct||||Globals:Off|||
Monophonic||||||:Off||||||OutPair:KDFX-A
||||||||||||||||||||||||||||||||||||||||
||||||||||||||||||||||||||||||||||||||||
||||||||||||||||||||||||||||||||||||||||
||||||||||||||||||||||||||||||||||||||||
<more||OUTPUT||||||||COMMON|SetRng|more>
Notice that when the Monophonic parameter is set to its default value of Off, the four
monophonic parameters do not appear on the page.
Parameter Range of Values Default
Pitch Bend Range ± 7200 Cents 200 Cents
Monophonic Off, On Off
(Legato Play) Off, On Off
(Portamento) Off, On Off
(Portamento Rate) 1 To 3000 keys per second 70
(Attack Portamento) Off, On On
Globals Off, On Off
OutPair KDFX-A, KDFX-B, KDFX-C, KDFX-D KDFX-A
