2M4/2M5/2M6/2M7
2-1-2
(2) Manual feed section (25/26 ppm model only)
Manual feed section consists of the MF sheet, MF base and the paper feed pulley (same as the cassette) for
extracting and conveying the paper.
Paper is fed out of the MF tray by the rotation of the paper feed pulley.Paper is automatically fed from the
manual feed tray if paper is present in the tray.
Figure 2-1-2 Manual feed section
2 3
1
1. MF sheet
2. MF base
3. MF guide R/L
