Kyocera ECOSYS FS-1020MFP User Manual

2M4/2M5/2M6/2M7
2-2-2
List of correspondences of PWB names
No. Name used in service manual Name used in parts list
1 Main PWB (MPWB) :20/21 ppm model PARTS PWB ASSY MAIN SP 20ppm
Main PWB (MPWB) :25/26 ppm model PARTS PWB ASSY MAIN SP
2 Relay PWB (RPWB) -
3 Power source PWB (PSPWB): 120V model PARTS SWITCHING REGULATOR 120V SP
Power source PWB (PSPWB):220-240V model PARTS SWITCHING REGULATOR 230V SP
4 High voltage PWB (HVPWB) PARTS HIGH VOLTAGE UNIT SP
5 Container PWB (CPWB) PARTS PWB ASSY CONTAINER CONNECT SP
6 Operation PWB(OPWB) PARTS PWB ASSY PANEL SP
7 APC PWB (APCPWB) -
8 Eraser lamp PWB (ELPWB) PARTS PWB ASSY ERASER SP
9 FAX control PWB (FCPWB) PARTS FAX UNIT SP

Kyocera ECOSYS FS-1020MFP Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Monthly Duty Cycle	20, 000 pages
Time to First Page	8.5 seconds
Duplex Print Mode	Manual
Scan Type	Flatbed
Output Capacity	100 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Memory	32 MB
Print Speed	20 ppm
Copy Speed	20 pages per minute
Maximum Scan Area	8.5 x 14 inches
Fax Transmission Speed	Not supported
