2M4/2M5/2M6/2M7
2-3-7
YC19 1 +3.3VTMG O 3.3 V DC 3.3 V DC power to DPTS
Connected to
DP motor,
DP original
sensor and
DP timing
sensor
2 GND - - Ground
3 TIMIG I 0/3.3 V DC DPTS: On/Off
4 +3.3VPAP O 3.3 V DC 3.3 V DC power to DPOS
5 GND - - Ground
6 DPPAPER I 0/3.3 V DC DPOS: On/Off
7 DPMOTB2 O 0/24 V DC (pulse) DP motor control signal
8 DPMOTB1 O 0/24 V DC (pulse) DP motor control signal
9 DPMOTA2 O 0/24 V DC (pulse) DP motor control signal
10 DPMOTA1 O 0/24 V DC (pulse) DP motor control signal
YC20 1 +24VERASER O 24V DC 24 V DC power to CL
Connected to
Eraser lamp
2 ERASER O 0/3.3 V DC CL: On/Off
YC22
1 THERM I Analog Outer thermistor signal
Connected to
outer temper-
ature sensor
2 +3.3V3 O 3.3 V DC 3.3 V DC power to OTEMS
3 AIRWET I Analog Data signal
4 WETCLK O 0/3.3 V DC (pulse) Clock signal
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS FS-1020MFP Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Monthly Duty Cycle	20, 000 pages
Time to First Page	8.5 seconds
Duplex Print Mode	Manual
Scan Type	Flatbed
Output Capacity	100 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Memory	32 MB
Print Speed	20 ppm
Copy Speed	20 pages per minute
Maximum Scan Area	8.5 x 14 inches
Fax Transmission Speed	Not supported
