Kyocera ECOSYS FS-1020MFP User Manual

2M4/2M5/2M6/2M7
2-3-13
Connector Pin Signal I/O Voltage Description
YC2 1 +24V3 O 24V DC 24 V DC power to DUSOL
Connected
to duplex
solenoid
(25/26 ppm
model)
2 DUSOLDRN O DC0V/24V DUSOL: On/Off
YC3 1 +24V3 O 24V DC 24 V DC power to PFSOL
Connected
to paper
feed sole-
noid
2 FFEDSOLDRN O DC0V/24V PFSOL: On/Off
YC4 1 OUTA O 0/24 V DC (pulse) MM control signal
Connected
to main
motor
2 OUTB O 0/24 V DC (pulse) MM control signal
YC5 1 +24V3 O 24V DC 24 V DC power to FM
Connected
to fan motor
2 FANDRN O DC0V/24V FM: On/Off
YC6 1 +24V3 O 24V DC 24 V DC power to TS
Connected
to toner
sensor
2 TONER SENSOR I DC0V/24V TS: On/Off
3 GND - - Ground
YC7 1 3.3V3 O 3.3 V DC 3.3 V DC power to CPWB
Connected
to container
PWB
2 SECCLK O 0/3.3 V DC (pulse) Clock signal
3 SECDATA I 0/3.3 V DC Data signal
4 GND - - Ground
YC8 1 3.3V3 O 3.3 V DCREG 3.3 V DC power to RS
Connected
to registra-
tion sensor
2 GND - - Ground
3 REGIST I 0/3.3 V DC RS: On/Off

Kyocera ECOSYS FS-1020MFP Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Monthly Duty Cycle	20, 000 pages
Time to First Page	8.5 seconds
Duplex Print Mode	Manual
Scan Type	Flatbed
Output Capacity	100 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Memory	32 MB
Print Speed	20 ppm
Copy Speed	20 pages per minute
Maximum Scan Area	8.5 x 14 inches
Fax Transmission Speed	Not supported
