Kyocera ECOSYS FS-1020MFP

2M4/2M5/2M6/2M7
2-4-5
9. Open the front cover.
Figure 2-4-7
10. Pull out the toner container.
Figure 2-4-8
* : Do not close the front cover.
* : Do not close the front cover while the
toner container is not installed, other-
wise, the cover-open detecting lever
may be damaged.
Figure 2-4-9
Front cover
Toner container
Front cover
