2M4/2M5/2M6/2M7-1

1-2-8

3 in 1 20/21 ppm model

1. Remove seven tapes.

Figure 1-2-10

2. Open the cassette.

3. Remove tape.

Figure 1-2-11

Tape

Tape

Tape s

Cassette

Tape
