2M4/2M5/2M6/2M7
1-3-22
Maintenance
menu
Items Description
Adjust scan
position
Scanning start
position
Type or select the start position for the platen, from -10 to +1
mm. Type or select the start position for the document pro-
cessor, from -3 to +10 mm.
Each unit of change moves the position by 0.1mm.
Adjusts the position of the
scanned image.
Scan margins Type or select the scan margins of all edges for the platen
and document processor, from 0 to 10 mm.
A higher setting makes the margin wider.
A lower setting makes the margin narrower.
Scan margins Adjusts the
width of the top edge, bottom
edge, left edge and right
edge margins.
Factory Default Restore Default
This feature restores the device to the factory default set-
tings.
Platen Top:-10, Left:0
Top:10, Bottom:0,
Left:0,Right:0
Top edge
Bottom edge
Right edge
Left edge
