Kyocera ECOSYS FS-1020MFP User Manual

2M4/2M5/2M6/2M7-1
1-4-3
0508 No paper feed from duplex
section(25/26ppm model)
Registration sensor (RS) does not turn on in 2.4
seconds after the duplex sensor (DUS) has turned
on, during paper is feed from the duplex section.
A
0511 Multiple sheets in cassette Registration sensor (RS) does not turn off in (3.4/
2.7)*1 seconds after the registration sensor (RS)
has turned on, during paper is feed from the cas-
sette or MF tray.
B
0518 Multiple sheets in duplex
section(25/26ppm model)
Registration sensor (RS) does not turn off in 2.7
seconds after the registration sensor (RS) has
turned on, during paper is feed from the duplex
section.
B
4020 Registration sensor on
(Power up or warm up)
Paper is present at the registration sensor (RS)
during power up or warm up.
B
4201 Duplex sensor non arrival
jam(25/26ppm model)
Duplex sensor (DUS) does not turn on in 1.0 sec-
onds after the registration sensor (RS) has turned
on, during paper is feed from the cassette or MF
tray.
B,C
4208 Duplex sensor non arrival
jam(25/26ppm model)
Duplex sensor (DUS) does not turn on in 1.0 sec-
onds after the registration sensor (RS) has turned
on, during paper is feed from the duplex section.
A
4211 Duplex sensor stay jam(25/
26ppm model)
Duplex sensor (DUS) does not turn off in 1.0 sec-
onds after the registration sensor (RS) has turned
off, during paper is feed from the cassette or MF
tray.
A
4218 Duplex sensor stay jam(25/
26ppm model)
Duplex sensor (DUS) does not turn off in 1.0 sec-
onds after the registration sensor (RS) has turned
off, during paper is feed from the duplex section.
A
4220 Duplex sensor on
(25/26ppm model)
(Power up or warm up)
Paper is present at the duplex sensor (DUS) during
power up or warm up.
A
4301 Duplex sensor non arrival
jam(25/26ppm model)
The duplex sensor (DUS) won’t turn on in 0.6 sec-
ond after a certain period of time switch-back has
started (cassette and MPF feeding).
B,C
4311 Duplex sensor stay jam(25/
26ppm model)
The duplex sensor (DUS) won’t turn off in 3.0 sec-
ond after a certain period of time switch-back has
started (cassette and MPF feeding).
A
9000 No paper feed from DP*2 DP timing sensor (DPTS) does not turn on during
original feed from DP (Retry 5 times).
D
9001 Narrow JAM*2 DP timing sensor (DPTS) was turned off while the
paper has travelled 53.2 mm after DP timing sen-
sor (DPTS) had been turned on.
D
9002 DP Initial jam*2 The DP timing sensor (DPTS) is turned on at the
start of paper feeding.
D
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-1 for paper misfeed indication (see page 1-4-1).

Kyocera ECOSYS FS-1020MFP Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Monthly Duty Cycle	20, 000 pages
Time to First Page	8.5 seconds
Duplex Print Mode	Manual
Scan Type	Flatbed
Output Capacity	100 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Memory	32 MB
Print Speed	20 ppm
Copy Speed	20 pages per minute
Maximum Scan Area	8.5 x 14 inches
Fax Transmission Speed	Not supported
