Kyocera ECOSYS FS-1020MFP User Manual

2M4/2M5/2M6/2M7
1-4-19
(10)
DP motor does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
DP motor and main PWB (YC19)
2. Defective drive trans-
mission system.
Check if the rollers and gears rotate smoothly. If not,
grease the bushes and gears. Check for broken gears and
replace if any.
3. Defective motor. Replace the DP motor.
4. Defective PWB. Replace the main PWB and check for correct operation
(see page 1-5-18)
(11)
An original jams
when the main
power switch is
turned on.
1. A piece of paper torn
from an original is
caught around the
DP original sensor,
DP timing sensor.
Check visually and remove it, if any.
2. Defective sensor.
Replace the DP original sensor, DP timing sensor.
Problem Causes Check procedures/corrective measures

Kyocera ECOSYS FS-1020MFP Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Monthly Duty Cycle	20, 000 pages
Time to First Page	8.5 seconds
Duplex Print Mode	Manual
Scan Type	Flatbed
Output Capacity	100 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Memory	32 MB
Print Speed	20 ppm
Copy Speed	20 pages per minute
Maximum Scan Area	8.5 x 14 inches
Fax Transmission Speed	Not supported
