Kyocera FS-C8500DN Service Manual

2KA
1-3-99
U910
Clearing the coverage data
Description
Clears the accumulated data for the digital dot coverage per A4 size paper in all colors.
Purpose
To clear data as required at times such as during maintenance service.
Method
1. Press the OK key.
2. Select [Execute].
3. Press the OK key. The digital dot coverage data is cleared.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
U911
Checking copy counts by paper sizes
Description
Displays the paper feed counts by paper sizes.
Purpose
To check the counts after replacing consumable parts.
Method
1. Press the OK key. The screen for the paper feed counts by paper size is displayed.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
U917
Setting backup data reading/writing
Description
Retrieves the backup data to a USB memory from the machine; or writes the data from the USB memory to
the machine.
Purpose
To store and write data when replacing the HDD.
Method
1. Turn the main power switch off.
2. Insert USB memory in USB memory slot.
3. Turn the main power switch on.
4. Enter the maintenance item.
5. Press the OK key.
6. Select [Import] or [Export].
7. Select the item.
8. Press the OK key. Starts reading or writing.
The progress of selected item is displayed in %.
When an error occurs, the operation is canceled and an error code is displayed (see page 1-3-100).
9. When normally completed, [Fin] is displayed.
10. Turn the main power switch off and on after completing writing when selecting [Import].
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
Import Writing data from the USB memory to the machine
Export Retrieving from the machine to a USB memory
Display Description
Job Accnt. Job accounting information/Job accounting setting information
Document Box Document box information
Display Description
Job Accnt. Job accounting information/Job accounting setting information
Document Box Document box information

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE
