Kyocera FS-C8500DN - 1-1-2 Parts names; (1) Body

2KA
1-1-3
1-1-2 Parts names
(1) Body
Figure 1-1-1
7
1
6
8
3
2
4
5
9
10
11
13
14
12
1. Operation panel
2. USB memory slot
3. Front cover
4. Cassette 1
5. Cassette 2
6. Top cover
7. Top tray
8. Left cover 1
9. Left cover 1 indicator
10. Left cover 1 lever
11. Left cover 2 indicator
12. Left cover 2
13. Left cover 3
14. Handles
