Kyocera FS-C8500DN - 1-6-2 Remarks on main PWB replacement

2KA
1-6-2
1-6-2 Remarks on main PWB replacement
When replacing the main PWB, remove the EEPROM from the main PWB that has been removed and then reattach it to
the new main PWB.
Figure 1-6-2
DDR
DIMM
EEPROM
Main PWB
