Kyocera FS-C8500DN Service Manual

2KA
1-6-3
When removing YC1, YC3, YC4, YC8 and YC9 from the main PWB, press the lock lever.
Figure 1-6-3
Connector
(YC3, YC4)
Connector
(YC3)
Connector
(YC4)
Locl lever
Locl lever
Connector (YC1)
Connector
(YC1)
Lock lever
Connector
(YC8, YC9)
Lock lever
Lock lever
Connector
(YC9)
Connector (YC8)
