Kyocera FS-C8500DN Service Manual

2KA
1-4-21
Partial operation control
If one of the following service codes is detected, partial operation control will be activated. Take actions to clear the cause
of the trouble and perform maintenance item U906 to reset partial operation control.
Code Contents
C0840 Faults of RTC
C1010 Lift motor 1 error
C1020 Lift motor 2 error
C1030 PF lift motor 1 error (optional paper feeder)
C1040 PF lift motor 2 error (optional paper feeder)
C1100 PF lift motor 1 error (optional 3000-sheet paper feeder)
C1110 PF lift motor 2 error (optional 3000-sheet paper feeder)
C1120 PF left lift position problem (optional 3000-sheet paper feeder)
C1130 PF right lift position problem (optional 3000-sheet paper feeder)
C2600 PF paper conveying motor error (optional paper feeder)
C8020 Punch motor problem (optional 3000-sheet document finisher)
C8030 Tray upper limit detection problem (optional document finisher)
C8040 Belt problem (optional document finisher)
C8050 Paper conveying belt motor 1 problem (optional 3000-sheet document finisher)
C8060 Paper conveying belt motor 2 problem (optional 3000-sheet document finisher)
C8070 Inner tray communication error (optional 3000-sheet document finisher)
C8140 Main tray problem (optional 3000-sheet document finisher)
Tray elevation motor problem (optional document finisher)
C8170 Side registration motor 1 problem (optional 3000-sheet document finisher)
C8180 Side registration motor 2 problem (optional 3000-sheet document finisher)
C8210 Stapler moving motor 1 error (optional 3000-sheet document finisher)
Stapler problem (optional document finisher)
C8220 Stapler moving motor 2 error (optional 3000-sheet document finisher)
C8230 Stapler motor problem (optional 3000-sheet document finisher)
C8300 Center-folding unit communication error (optional center-folding unit of 3000-sheet document finisher)
C8310 Centerfold side registration motor 2 problem (optional center-folding unit of 3000-sheet document finisher)
C8320
Centerfold paper conveying belt motor problem (optional center-folding unit of 3000-sheet document finisher)
Adjustment motor 2 problem (optional document finisher)
C8330 Blade motor problem (optional center-folding unit of 3000-sheet document finisher)
Adjustment motor 1 problem (optional document finisher)
C8340 Centerfold staple motor problem (optional center-folding unit of 3000-sheet document finisher)
C8350 Centerfold side registration motor 1 problem (optional center-folding unit of 3000-sheet document finisher)
Roller motor problem (optional document finisher)
C8360 Centerfold main motor problem (optional center-folding unit of 3000-sheet document finisher)
Slide motor problem (optional document finisher)
C8440 Sensor adjusting problem (optional document finisher)
C8460 EEPROM problem (optional document finisher)
C8500 Mailbox communication error (optional mailbox of 3000-sheet document finisher)
C8510 Mailbox drive motor problem (optional mailbox of 3000-sheet document finisher)

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
