Kyocera FS-C8500DN Service Manual

2KA
1-4-30
C2233 Drum motor M main sensor error
No signal is input to the sensor for 1.5 s
continuously.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC5 on
the motor control PWB and the connector of
the drum motor M, and the continuity across
the connector terminals. Repair or replace if
necessary.
Defective drum
motor M.
Replace the drum motor M.
Defective PWB. Replace the motor control PWB or engine
PWB and check for correct operation.
C2234 Drum motor Y main sensor error
No signal is input to the sensor for 1.5 s
continuously.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC7 on
the motor control PWB and the connector of
the drum motor Y, and the continuity across
the connector terminals. Repair or replace if
necessary.
Defective drum
motor Y.
Replace the drum motor Y.
Defective PWB. Replace the motor control PWB or engine
PWB and check for correct operation.
C2241 Drum motor K sub sensor error
No signal is input to the sensor for 1.5 s
continuously.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC8 on
the motor control PWB and the connector of
the drum motor K, and the continuity across
the connector terminals. Repair or replace if
necessary.
Defective drum
motor K.
Replace the drum motor K.
Defective PWB. Replace the motor control PWB or engine
PWB and check for correct operation.
C2242 Drum motor C sub sensor error
No signal is input to the sensor for 1.5 s
continuously.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC6 on
the motor control PWB and the connector of
the drum motor C, and the continuity across
the connector terminals. Repair or replace if
necessary.
Defective drum
motor C.
Replace the drum motor C.
Defective PWB. Replace the motor control PWB or engine
PWB and check for correct operation.
C2243 Drum motor M sub sensor error
No signal is input to the sensor for 1.5 s
continuously.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC5 on
the motor control PWB and the connector of
the drum motor M, and the continuity across
the connector terminals. Repair or replace if
necessary.
Defective drum
motor M.
Replace the drum motor M.
Defective PWB. Replace the motor control PWB or engine
PWB and check for correct operation.
Code Contents
Remarks
Causes Check procedures/corrective measures
