Figure 1-2-3 Unpacking
Place the machine on a level surface.
Unpacking.
1
17
7
8
11
13
18
20
21
22
23
24
25
15
16
26
19
14
12
9
10
4
5
6
3
2
28
28
28
28
28
28
30
34
33
31
32
29
28
28
27
1. Machine
2. Upper lid
3. Outer case
4. Inner frame
5. Upper left pad
6. Upper right pad
7. Skid
8. Bottom sheet
9. Bottom pad
10. Plastic bag
11. Bottom front left pad
12. Bottom front right pad
13. Bottom rear left pad
14. Bottom rear right pad
15. Left pad
16. Front pad
17. Machine cover
18. Document tray
19. Power code
20. Plastic bag
21. Operation guide
22. Plastic bag
23. Jumper connector
24. Plastic bag
25. Cursor pins
26. Size plates
27. Barcode label
28. Hinge joints
29. Upper pad
30. Toner container K
31. Toner container Y
32. Toner container M
33. Toner container C
34. Waste toner box
