2KA
2-3-26
YC100 1 +3.3V O 3.3 V DC 3.3 V DC power to OPPWB
Connected to
the operation
panel PWB
2 GND - - Ground
3 FPRST O 0/3.3 V DC OPPWB reset signal
4 FPTXD O 0/3.3 V DC (pulse) OPPWB serial communication data signal
5 FPD_SEL O 0/3.3 V DC OPPWB select signal
6 FPCTS I 0/3.3 V DC OPPWB control signal
7 FPRXD I 0/3.3 V DC (pulse) OPPWB serial communication data signal
8 GND - - Ground
9 +5V1V O 5 V DC 5 V DC power to OPPWB
Connector Pin No. Signal I/O Voltage Description
