Connector Pin No. Signal I/O Voltage Description
YC1 1 +24V2 O 24 V DC 24 V DC power to PFCL2
Connected to
the paper
feed clutch 2
2 FED2 CLT REM O 0/24 V DC PFCL2: On/Off
YC2 1 +24V2 O 24 V DC 24 V DC power to PCM
Connected to
the paper
conveying
motor
2 +24V2 O 24 V DC 24 V DC power to PCM
3PGND -- Ground
4PGND -- Ground
5 FEED MT RDY I 0/3.3 V DC PCM ready signal
6 FEED MT DR O 0/3.3 V DC PCM: On/Off
7 FEED MT DIR O 0/3.3 V DC PCM drive switch signal
8 FEED MT CLK O 0/3.3 V DC (pulse) PCM clock signal
YC3 1 LFT1 MOT SIG2 I 0/3.3 V DC LM1 paper gauge signal
Connected to
the lift motor
1/2
2PGND -- Ground
3 LFT1 MOT SIG1 I 0/3.3 V DC LM1 paper gauge signal
4 LFT1 MOT DR2 O 0/24 V DC LM1 drive control signal
5 LFT1 MOT DR1 O 0/24 V DC LM1 drive control signal
6 LFT2 MOT SIG2 I 0/3.3 V DC LM2 paper gauge signal
7PGND -- Ground
8 LFT2 MOT SIG1 I 0/3.3 V DC LM2 paper gauge signal
9 LFT2 MOT DR2 O 0/24 V DC LM2 drive control signal
10 LFT2 MOT DR1 O 0/24 V DC LM2 drive control signal
YC4 1 +5V1 O 5 V DC 5 V DC power to LSW1
Connected to
the lift switch
1/2 and paper
switch 1/2
2 CAS1 LFT UP I 0/3.3 V DC LSW1: On/Off
3 GND - - Ground
4 +5V1 O 5 V DC 5 V DC power to PSW1
5 CAS1 EMPTY I 0/3.3 V DC PSW1: On/Off
6 GND - - Ground
7 +5V1 O 5 V DC 5 V DC power to LSW2
8 CAS2 LFT UP I 0/3.3 V DC LSW2: On/Off
9 GND - - Ground
10 +5V1 O 5 V DC 5 V DC power to PSW2
11 CAS2 EMPTY I 0/3.3 V DC PSW2: On/Off
12 GND - - Ground
YC5 1 +24V2 O 24 V DC 24 V DC power to PFCL1
Connected to
the paper
feed clutch 1
2 FED1 CLT REM O 0/24 V DC PFCL2: On/Off
YC6 1 +24V2 I 24 V DC 24 V DC power from EPWB
Connected to
the engine
PWB
2 +24V2 I 24 V DC 24 V DC power from EPWB
3 +24V2 I 24 V DC 24 V DC power from EPWB
4PGND -- Ground
5PGND -- Ground
6PGND -- Ground
7PGND -- Ground
8 +5V1 I 5 V DC 5 V DC power from EPWB
