Kyocera FS-C8500DN Service Manual

2
VW
U
S
T
Y
Z
X
AK-720
AA
AC
AD
AB
AA プレート ........................... 1
AB 組立ベース ......................... 1
AC ビス M4 × 10 タップタイト S .......... 8
AD ビス M4 × 14TP 並目 ................. 1
ドキュメントフィニッシャを設置する場合、
ジョブセパレータに付属する (S),(T),(U),(V)
8 本が必要となる。
DF-720 を設置する場合のみ (V),(W),(X) が必要
となる。
S 固定板 F ............................1
T 固定板 R ............................1
U カバーAT............................1
V ビス M4 × 10 タップタイト S .......... 9
W 段付きビス ......................... 1
X ガイド板 ........................... 1
ドキュメントフィニッシャを設置する場合、
(Y),(Z),(AA),(AB),(AC),(AD) が必要となる。
Y ベーススライダ B .................... 1
Z ベーススライダ V .................... 1
When installing the document finisher, (S), (T),
(U) and eight (V) supplied with the job separator
are needed.
Remaining parts (V), (W), and (X) are required
only when installing DF-720.
S Fixing plate F .......................................... 1
T Fixing plate R .......................................... 1
U Cover AT ................................................. 1
AA Plate........................................................ 1
AB Assembly base ....................................... 1
AC M4 × 10 tap Tight S screw ..................... 8
AD M4 x 14TP coarse thread screw ............. 1
Lors de l’installation du retoucheur de
documents sur une MFP polychrome, les pièces
(S), (T), (U) et 8 des 9 (V) fournies avec le
séparateur de travaux sont requises. Les pièces
restantes (V), (W) et (X) ne sont requises que
pour l’installation de DF-720.
S Plaque de fixation avant .......................... 1
T Plaque de fixation arrière......................... 1
Y Règle de base B ..................................... 1
Z Règle de base V ..................................... 1
AA Plaque..................................................... 1
AB Base d’ensemble ................................... 1
AC Vis S taraudée M4 × 10 ......................... 8
AD Vis à filet normal M4 x 14TP................... 1
Cuando instale el finalizador de documentos en
una MFP a todo color serán necesarias las
partes (S), (T) y (U), y ocho de los nueve
tornillos (V) suministrados con el separador de
tareas. El resto de las partes (V), (W) y (X) sólo
serán necesarias cuando se instale el DF-720.
S Placa de fijación F .................................. 1
T Placa de fijación R .................................. 1
Y Deslizador de base B .............................. 1
Z Deslizador de base V .............................. 1
AA Placa.......................................................1
AB Base del conjunto .................................. 1
AC Tornillo de ajuste M4 × 10 ......................8
AD Tornillo de rosca gruesa M4 x 14TP ....... 1
Wenn der Dokument-Finisher auf einem
Farbmultifunktionsgerät angebracht wird, sind
die Teile (S), (T), (U) und acht von neun (V)
Schrauben die mit dem Jobtrenner gelieferten
erforderlich. Die verbleibenden Teile (V), (W),
und (X) sind nur dann erforderlich, wenn der
DF-720 aufgestellt wird.
S Fixierplatte F............................................ 1
T Fixierplatte R .......................................... 1
Y Basis-Schieber B .................................... 1
Z Basis-Schieber V .................................... 1
AA Platte....................................................... 1
AB Bauteile-Basis ........................................1
AC M4 × 10 Passstift-Verbundschrauben .... 8
AD M4 x 14 TP Grobgewindeschraube ........ 1
Per l’installazione della finitrice di documenti su
un MFP a colori, sono necessarie le parti (S),
(T), (U) e otto su nove (V) fornite in dotazione
con il separatore dei lavori. Le rimanenti parti
(V), (W) e (X) sono necessarie solo nel caso di
installazione del DF-720.
S Piastra di fissaggio F ............................... 1
T Piastra di fissaggio R .............................. 1
Y Scivolo di base B ..................................... 1
Z Scivolo di base V ..................................... 1
AA Piastra..................................................... 1
AB Base di assemblaggio ............................1
AC Vite con testa a croce S M4 × 10 ........... 8
AD
Vite con filettatura a passo grosso M4 x 14TP ..1
安装装订器时，需使用随作业分离器附带的
（S）、（T）、（U）部件和 8 颗（V）螺丝。
只有安装 DF-720 时才需要使用剩余的部件（V）、
（ W ）和（ X ）。
S 固定板 F .................................................. 1
T 固定板 R .................................................. 1
U 盖板 AT .................................................... 1
V M4 × 10 攻丝紧固型 S 螺丝...................... 9
W 带肩螺丝.................................................. 1
X 导向板 ..................................................... 1
安装装订器时，需要使用（Y）、（Z）、（AA）、
（AB）、（ A C ）和（ A D ）。
Y 底座滑板 B............................................... 1
Z 底座滑板 V............................................... 1
AA 板 ............................................................ 1
AB 组装底座.................................................. 1
AC M4 × 10 攻丝紧固型 S 螺丝...................... 8
AD M4 × 14TP 粗牙螺丝................................. 1
V M4 × 10 tap Tight S screw ...................... 9
W Shoulder screw ....................................... 1
X Guide plate ............................................. 1
When installing the document finisher, (Y), (Z),
(AA), (AB), (AC) and (AD) are needed.
Y Base slider B ........................................... 1
Z Base slider V ........................................... 1
U Couvercle AT ........................................... 1
V Vis S taraudée M4 × 10 ........................... 9
W Vis d’épaule ............................................ 1
X Plaque guide ........................................... 1
Lors de l’installation du retoucheur de document
sur une machine entièrement en couleurs, les
pièces (Y), (Z), (AA), (AB), (AC) et (AD) sont
requises en plus.
U Cubierta AT ............................................. 1
V Tornillo de ajuste M4 × 10........................ 9
W Tornillo de hombro .................................. 1
X Placa guía ............................................... 1
Cuando el finalizador de documentos se instale
en una máquina a todo color serán necesarias
también las partes (Y), (Z), (AA), (AB) (AC) y
(AD).
U Abdeckung AT ........................................ 1
V M4 × 10 Passstift-Verbundschraube........ 9
W Bundschraube ......................................... 1
X Führungsplatte ........................................ 1
Wenn der Dokument-Finisher auf einem
Vollfarbenkopierer angebracht wird, so sind
zusätzlich die Teile (Y), (Z), (AA), (AB), (AC) und
(AD) erforderlich.
U Coperchio AT ........................................... 1
V Viti con testa a croce S M4 × 10.............. 9
W Vite a colletto ........................................... 1
X Piastra della guida ................................... 1
Per l’installazione della finitrice di documenti in
un macchinario a colori, sono necessarie in
aggiunta le parti (Y),(Z),(AA),(AB),(AC) e (AD).

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
