Kyocera FS-C8500DN Service Manual

2KA
1-3-23
U032
Checking the operation of the clutches
Description
Turns each clutch on.
Purpose
To check the operation of each clutch.
Method
1. Press the OK key.
2. Select [Motor On] or [Motor Off].
3. Press the OK key.
4. Select the clutch to be operated.
5. Press the OK key. The clutch turns on for 1 s.
To stop motor driving, press the Back key.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
U033
Checking the operation of the solenoids
Description
Applies current to each solenoid in order to check its ON status.
Purpose
To check the operation of each solenoid.
Method
1. Press the OK key.
2. Select [Motor On] or [Motor Off].
3. Press the OK key.
4. Select the solenoid to be operated.
5. Press the OK key. The solenoid turns on for 1 s.
To stop motor driving, press the Back key.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Clutches
Motor On The paper conveying motor (PCM) is turned on.
Motor Off The paper conveying motor (PCM) is turned off.
Display Clutches
Feeder 1 Paper feed clutch 1 (PFCL1)
Feeder 2 Paper feed clutch 2 (PFCL2)
MPT Feed On/Off MP paper feed clutch (MPPFCL)
Vertical Conv. 1 Feed clutch 1 (FCL1)
MPT Feed MP paper conveying clutch (MPPCCL)
Vertical Conv. 2 Feed clutch 2 (FCL2)
Fuser Release Fuser clutch (FUCL)
Display Clutches
Motor On The paper conveying motor (PCM) is turned on.
Motor Off The paper conveying motor (PCM) is turned off.
Display Solenoids
Eject Branch Feedshift solenoid (FSSOL)
MPT Pick Up MP solenoid (MPSOL)
