Kyocera FS-C8500DN Service Manual

2KA
1-3-52
U135
Checking toner motor operation
Description
Drives toner motors.
Purpose
To check the operation of toner motors.
Remarks
When driving the toner motors long time or several times, developing section becomes the toner full and is
locked.
Method
1. Press the OK key.
2. Select the motor to be operated.
3. Press the OK key. The operation starts.
4. To stop the operation, press the Back key.
Completion
Press the Back key after operation stops. The screen for selecting a maintenance item No. is displayed.
U136
Setting toner near end detection
Description
Sets the level that indicates the number of sheets that can be printed from occurrence of toner near end to
toner empty.
Purpose
To change the setting to advance detection of near end if the interval from toner near end to toner empty
seems too short.
Setting
1. Press the OK key.
2. Select the item to be set.
3. Change the value using the Left/Right Select keys.
Increasing the setting makes the interval from toner near end to toner empty longer.
Decreasing the setting makes the interval from toner near end to toner empty shorter.
If 0 is set, toner near end will not be detected.
4. Press the OK key. The value is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Operation
Toner Feed Toner motor (TM) is turned on
Container (CW) Toner container motor (TCM) is turned on counterclockwise
Container (CCW) Toner container motor (TCM) is turned on clockrwise
Display Description
Setting
range
Initial
setting
B/W Setting the level of black toner 0 to 9 3
CMY Setting the level of cyan/magenta/yellow toner 0 to 9 3
