Kyocera FS-C8500DN Service Manual

2KA
1-3-54
U140
Displaying developing bias
Description
Displays various developing bias value.
Purpose
To check the developing bias value.
Method
1. Press the OK key.
2. Select an item to be set.
3. Press the OK key. The screen for setting each item is displayed.
Setting: [Dev Roll2 DC]
1. Select the item to be set.
2. Change the value using the Left/Right Select keys.
3. Press the OK key. The value is set.
Setting: [Dev Roll1(Calib)DC]
1. Select the item to be set.
2. Change the value using the Left/Right Select keys.
3. Press the OK key. The value is set.
Maintenance
item No.
Description
Display Description
Dev Roll2 DC Developing sleeve roller DC bias
Dev Roll1(Calib)DC Developing magnet roller DC bias (toner thick layer calibration)
Dev Roll2 AC Developing sleeve roller AC bias
Dev Roll1DC Developing magnet roller DC bias
Roll1 DC Int Developing magnet roller paper interval DC bias
Dev Roll1AC Developing magnet roller AC bias
DEV Roll Freq Developing magnet roller frequency
DEV Roll Duty Developing magnet roller duty
Dev Roll2 Duty Developing sleeve roller duty
Display Description
Setting
range
Initial
setting
Cyan Developing sleeve roller DC bias for cyan 0 to 255 93
Magenta Developing sleeve roller DC bias for magenta 0 to 255 93
Yellow Developing sleeve roller DC bias for yellow 0 to 255 93
BlacK Developing sleeve roller DC bias for black 0 to 255 93
Black/White Developing sleeve roller DC bias in black/white mode 0 to 255 93
Display Description
Setting
range
Initial
setting
DC1 K Developing magnet roller DC1 bias for black 0 to 255 112
DC2 K Developing magnet roller DC2 bias for black 0 to 255 142
DC3 K Developing magnet roller DC3 bias for black 0 to 255 173
DC4 K Developing magnet roller DC4 bias for black 0 to 255 204
DC1 CMY Developing magnet roller DC1 bias for cyan/magenta/yellow 0 to 255 112
DC2 CMY Developing magnet roller DC2 bias for cyan/magenta/yellow 0 to 255 142
DC3 CMY Developing magnet roller DC3 bias for cyan/magenta/yellow 0 to 255 173
DC4 CMY Developing magnet roller DC4 bias for cyan/magenta/yellow 0 to 255 204
