Kyocera KM-2560

2H0/2HZ
1-4-28
C8170 Adjustment motor problem
(optional document finisher)
When the adjustment motor is driving,
the ON status of the adjustment home
position sensor cannot be detected even
if a specified time has elapsed.
When adjustment operation starts, the
ON status of the adjustment home posi-
tion sensor is not detected.
The adjustment
motor connector
makes poor con-
tact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective adjust-
ment motor.
Replace adjustment motor.
The adjustment
home position sen-
sor connector
makes poor con-
tact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective adjust-
ment home posi-
tion sensor.
Replace the adjustment home position sen-
sor.
Defective finisher
main PWB.
Replace the finisher main PWB and check
for correct operation.
Finisher front side registration motor
problem (optional built-in finisher)
When the front-side registration home-
position sensor is turned on during initial-
ization, the sensor did not turn on while it
has moved by 106 pulses.
When the front-side registration home-
position sensor is turned off during initial-
ization, the sensor did not turn on in 3 s.
The front side reg-
istration motor con-
nector makes poor
contact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective front side
registration motor.
Replace front side registration motor.
The front side reg-
istration home
position sensor
connector makes
poor contact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective front side
registration home
position sensor.
Replace the front side registration home
position sensor.
Defective finisher
control PWB.
Replace the finisher control PWB and check
for correct operation.
C8180 Finisher rear side registration motor
problem (optional built-in finisher)
When the rear-side registration home-
position sensor is turned on during initial-
ization, the sensor did not turn on while it
has moved by 106 pulses.
When the rear-side registration home-
position sensor is turned off during initial-
ization, the sensor did not turn on in 3 s.
The rear side reg-
istration motor con-
nector makes poor
contact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective rear side
registration motor.
Replace rear side registration motor.
The rear side reg-
istration home
position sensor
connector makes
poor contact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective rear side
registration home
position sensor.
Replace the rear side registration home
position sensor.
Defective finisher
control PWB.
Replace the finisher control PWB and check
for correct operation.
Code Contents
Remarks
Causes Check procedures/corrective measures
