Kyocera KM-2560

2H0/2HZ
1-5-7
3. Open the front cover.
4. Remove the screw and remove the front
right cover.
Figure 1-5-11
5. Raise the top tray.
6. Remove ten hooks and remove the rigt
lower cover.
Figure 1-5-12
Front right cover
Front cover
Screw
Right lower cover
Right lower cover
Top tray
Hooks
