Kyocera KM-2560

2H0/2HZ
1-5-8
7. Loosen two screws and remove two MP
holder plates.
8. Remove two screws.
Figure 1-5-13
9. Remove two connectors.
10. Release the clamp.
11. Remove the MP unit.
Figure 1-5-14
Screw
Screw
MP holder
plate
MP holder
plate
Screw
Screw
Connector
Connector
Clamp
MP unit
