2NL/2P8
1-3-101
U247 Setting the paper feed device
Description
Turns on motor and clutches of paper feeder device.
Purpose
To check the operation of motor and clutches of paper feed device.
Method
1. Press the start key.
2. Select the paper feed device.
Method: [2PF]
1. Press [Motor] or [Device] and select the item.
2. Select [Execute].
3. Press the start key. The operation starts.
4. To stop operation, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
2PF Paper feeder
Display Description
Motor Off PF paper feed motor (PFPFM) is turned off
On PF paper feed motor (PFPFM) is turned on
Device C1 Clutch PF paper conveying clutch 1 (PFPCCL1) is turned on
C2 Clutch PF paper conveying clutch 2 (PFPCCL2) is turned on
V Feed Clutch PF paper feed clutch (PFPFCL) is turned on
H Feed1 Clutch PF paper conveying clutch 1 (PFPCCL1) is turned on
H Feed2 Clutch PF paper conveying clutch 2 (PFPCCL2) is turned on
Cassette1 Solenoid PF pickup solenoid 1 (PFPUSOL1) is turned on
Cassette2 Solenoid PF pickup solenoid 2 (PFPUSOL2) is turned on
