Kyocera TASKalfa 3510i - Page 79

2NL/2P8
1-2-55
19. Fix the cable cover on the machine.
Latch the three hooks at the near end
and press the hooks downwards to
mate with the holes at the far end.
Figure 1-2-75
20. Replace the staple holder.
Figure 1-2-76
Cable cover
Hook
Hook
Hook
Cable cover
Holes
Hole
Staple holder
