63Expert(t) 2000
TM
Maintenance Manual
packer. Pull the red button and
repeat the procedure until the
packer reaches the desired
position.
8. Turn the engine and hydraulic
pump off;
9. Unbolt both hopper side panels
(Figure 100. “Hopper side
panel”) located below the hopper
doors of the Expert(t) 2000
TM
;
Figure 100. Hopper side panel
10. Unbolt the deflector stands on
both sides of the hopper to
remove them. (Figure 101. “Side
rail and deflector stand”).
Figure 101. Side rail and deflector
stand
11. Unbolt the side rails from the
right- and left-hand side hopper
walls (Figure 101. “Side rail and
deflector stand” & Figure 102.
“Side rails removal”);
Figure 102. Side rails removal
12. When both side rails are
removed, remove the arm
DANGER
NEVER CLIMB IN THE HOPPER WHILE
THE
ENGINE IS RUNNING.
Hopper Side Panel
Deflector
Stand
Side Rail
Side Rail
