10 Appendix
10.11 Connections in Non Grounded Power Line Networks
If you use a ETAMATIC OEM in a non-grounded power line network, you have to connect the
ETAMATIC OEM upstrem to a mains filter.
Firing-rate input (term. 3 to term. 6) 100 m
LSB 500 m
ETAMATIC OEM
Signal Cable Length
No. Description
1 mains filter type 663 R 4050
2 ETAMATIC OEM
3 PE bar
