34
6 Commissioning
6.2.2 Clear Memory
Start burner (signal at terminal 58)
Wait until pre-purge has finished.
6.2.3 Programming the Ignition Point
6.2.4 Programming the Base Firing Rate
6.2.5 Programming the 3rd up the 10th Point
Proceed as described in "Program base firing rate point", but set each of the firing rate ratings
“250", "300", "400", "500", "600", "700", "800", "900", and "999" one after the other.
6.2.6 Saving Curve
press key twice the display shows "SL" in it’s centre.
press key the display shows "cleared". The old curve is cleared
press key the display shows "El" in the centre
use keys 16 and 17 to switch to "a.v. feedb."
use keys 2 to 9, to run the control elements to ignition position
press "Enter" key the display shows "Really ignite" .
if not, press key 3 and redefine ignition position
press "Enter" key again to confirm. the burner ignites
use keys 16 and 17 to switch to "firing rate value"
use keys 2 and 3 to set "200"
use keys 16 and 17 to switch to "a.v. feedb."
use the keys 2 to 9, to run the control elements to ignition position
press "Enter" key again to confirm.
use keys to switch from "Set" to "Automatic" the display shows "Memory"
