5 Operator Device
5 Operator Device
Fig. 5-1 Customer interface
Intent of the keys:
 Reset
 Firing rate/ Fault history up
 Firing rate / Fault history down
 Firing rate / Fault history down
 Manual operation on / off
– Fuel/air ratio control
–O
2
– Flame intensity
– Operating hours
Select operating modes*: PARAM  O
2
EI
1 )
 AUTO  EINS  SPLO*
Select operating parameters Status  firing rate rating  setpoint  Actual value feedback
 Digital inputs
PARM = Parameterisation
1)
only, if parameter is active
O
2
EI = O
2
setting
AUTO = Automatic
EINS = Setting
SPLO = Clear memory
