Lamtec ETAMATIC OEM - LSB Connection

121
10 Appendix
10.14.2 LSB Connection
Fig. 10-14 LSB connection ETAMATIC OEM to LT2
Fig. 10-15 LSB connection ETAMATIC OEM - LT2 - other LAMTEC devices
No. Description
1 To other LAMTEC-devices
2 Housing
3 Pre-canned line 2 m
4 PE-bar in housing LT2
5 Terminal resistance passive
