Fig. 10-16 LSB connection ETAMATIC OEM o LT1 from SN 600 on
Fig. 10-17 LSB-Connection ETAMATIC OEM - LT 1 to SN 0599
No. Description
1 PE-bar in housing LT1
2 Housing
3 Pre-canned line 2m, 663R0421N
4 LT1 from serial number 0600
5 Terminal resistance active
6 To other LAMTEC- devices
No. Description
1 PE-Track in system-cover LT1
2 Cover
3 Pre-canned line 2 m, 663R0421N
4 LT1 from serial number 0599
5 Terminator enable
