6 Commissioning
6.1.18.2 Adjusting Control Elements
Enter password (see chapter 6.1.2 Password Entry).
Display "s. p. feedback" ca. 80 - 100 digit at TPS-outputs. If the display shows other values,
you must adjust the limit switches in the motors and/or the potentiometers.
Display ca. 200 digit with ETAMATIC S OEM channel 1 with a feedback of 4...20 mA.
With integral speed evaluation the number of points depends on the setting of the frequency
converter (if necessary release fan manually).
WARNING!
Never change the settings of the frequency converter or the revolution measurement feed-
back after programming the setpoint values at ETAMATIC OEM. Otherwise you have to pro-
gram the curve again.
If other values are displayed, set limit switches and/or potentiometers in the motors accord-
ingly.
Display of ca. 999 digit at ETAMATIC S OEM channel 1 with a feedback of 4...20mA.
If other values are displayed, check the 4...20mA input (terminal 44 and 45) and check the set-
tings of the frequency converter.
6.2 Enter the Curve
Fuel selection
0V at terminal 49 = curve set 1 (oil curve)
+24V at terminal 49= curve set 2 (gas curve)
NOTICE
If the ETAMATIC OEM has 2 oil curves or 2 gas curves (parameter 776 at #1 (oil) or #2 (gas),
curve set 1 (0V) or curve set 3 (+24V) can be chosen for oil and curve set 2 or curve set 4 can
be chosen for gas.
use F2 and F3 to select "Set"
use the Keys 16 and 17 to set the display to "Parm"
use the keys 2, 4, 6 and 8 to set all actuators to setpoint value "000"
press key 16 the display shows the actual value feedback
press key 17 to set the display to setpoint
use the keys 3, 5, 7 and 9 to set all control elements to 999.
press key 16 the display shows the actual value feedback.
