15
5 Operator Device
5.2.3 Settings
5.2.3.1 DIP Switch
The DIP-switches SW 1.1 and SW 1.2 define the LSB-family 1...4 (0...3 binary).
Use the DIP-switches SW 1.3 ... SW 1.7 you can adjust the contrast in steps of 2 from 0...62
(default value after RESET).
With DIP-switch SW 1.8 you can define the terminator’s function for LAMTEC SYSTEM BUS
(LSB), the CAN Bus-terminator.
5.2.3.2 Description of the LED
SW 1.2 SW 1.1 LSB-Familie
off off 1
off on 2
on off 3
on on 4
SW 1.8 Terminator
off inactive
on active
LED Function
1 LSB CAN-H
2 LSB CAN-L
3 operating voltage
4 5V DC programming mode
