10 Appendix
NOTICE
LAMTEC SYSTEM BUS is to be wired as a chain!
Stub lines are not permitted!
For the cable length and cable cross-section of the LAMTEC SYSTEM BUS, please take note
of the following recommendations:
No. Description
1 Customer interface
2 Connecting cable 663P0421
3 Field bus module 663R040
PROFIBUS DP ETAMATIC
4 LSB Module
0-40 m 2 x 2 x 0,34 mm
2
wired as pairs with schielding 120
40-300 m 2 x 2 x 0,5 mm
2
wired as pairs with schielding 120
300-600 m 2 x 2 x 0,6 mm
2
wired as pairs with schielding 120
600-1000 m 2 x 2 x 0,75 mm
2
wired as pairs with schielding 120
