Egress actionIngress action
2. is not 0x8100, the frame is forwarded (no additional tag
added).
The TPID of frame transmitted by an
S-custom-port will be set to a self-customized
When the port receives an untagged frame, a tag - based on the
defined PVID - is added and the frame is forwarded.
When the port receives a tagged frame and the TPID
S-custom-port
value, which can be set by using the field
Ethertype for Custom S-ports.
1. is 0x8100, the frame is discarded.
2. is not 0x8100, the frame is forwarded (no additional tag
added).
83
LANCOM GS-2310P/GS-2326(P) User Manual
3 Configuration
