PLMNL0232 REV. H Effective Date: 01/14/19 19 FiberCUT
®
2D Operation Manual
3.2 Generation 1 Controllers
3.2.1 Interface Example
The control box interface allows
control and feedback of all the
FiberCUT
®
2D operations.
The interface example in Figure 20
is applicable for the following
Generation 1 Laser Mechanisms’
controllers:
Figure 20
