PLMNL0232 REV. H Effective Date: 01/14/19 23 FiberCUT
®
2D Operation Manual
 There are 3 digital inputs (Cal,
Reset and Move) available
through the terminal block
connection.
DIGITAL INPUTS
INPUTS
DESCRIPTION
Cal In
Activate Cal In for 100 – 200 msec
to calibrate the HSU.
Typically, Cal In is performed with
the standoff distance set to 12 mm.
Reset In
Activate Reset In for 100 – 200
msec to re-home the lens.
Move In
Activate Move In for 100 – 200
msec to send the lens to the
position specified by the analog
input.
~ Activate Move-In only after
In-Position is active.
~ Hold Move-In active for at least
100msec or until In-Position turns
off.
~ The move is complete after
In-Position turns on. (Lens In).
3.3.3 Industrial Ethernet Connection
The Industrial Ethernet interface
provides extensive control and
monitoring of the FiberCUT
®
2D.
Depending on the control box
model, either EtherNet/IP or
PROFINET communications
protocol is used.
See Appendix E for details on
device configuration and available
data.
3.3.4 Machine Sequence to Move the
Lens to the Desired Location
 See Section 3.3.2 for more
details on the inputs and
outputs.
1. Set the Lens-In analog input
voltage to correspond to the
desired lens location.
2. Verify the In-Pos digital output is
active.
3. Activate the Move In digital
input.
4. Wait for the In-Pos digital output
to deactivate.
 There is a delay while the
controller acknowledges the
command.
5. Deactivate the Move In digital
input.
6. Wait for In-Pos digital output to
activate.
 There is a delay while the
lens moves.
