6 Specifications
CUTTING HEAD
Power Rating .............................................................................................................................. up to 8 kW
Focusing Lens (Nominal Focal Length) ............................................................ 125 mm, 150 mm, 200 mm
Focusing Lens (Diameter) .............................................................................................................. 38.1 mm
Clear Aperture ................................................................................................................................... 35 mm
Nozzle Tip .............................................................................................. Various Shapes and Orifice Sizes
Assist Gas Pressure .................................................................................................. up to 25 Bar (375 psi)
Purge Gas ........................................................................................................ 0.2 – 0.3 Bar (3.0 – 5.0 psi)
Water ................................................................................................................ 5.0 Bar Max (72.5 psi max)
Weight ................................................................................................................................ 6.6 kg (14.5 lbs)
Focal Point to Nozzle Adjustment ................................................................................. -14 mm to +11 mm
COLLIMATOR
Nominal Focal Length (Doublet, Fused Silica) ...................................................... 60 mm, 80 mm, 100 mm
Fiber Socket (Others Available On Request) ......................................... QBH (HLC-8), QD (LCA) (LLK-D)
HEIGHT SENSOR
Standoff Distance Range ................................................................................................ 0.2 mm to 8.0 mm
Single Point Calibration ..................................................................................................................... 12 mm
Response Time .............................................................................................................................. <1 msec
Temperature Stability ......................................................................... ±5% of Standoff Setting, 0° to 45° C
Output ..................................................................................................................................... 0-10 V Analog
Specifications are subject to change without notice.
