12 Appendix E – Industrial Ethernet Data Mapping and Descriptions
12.1 EtherNet I/P I/O Mapping
The EDS file is available for download at http://www.lasermech.com/fibercut2dupdates
WORD
TYPE
NAME
0
Input Data
Digital Outputs
1
Input Data
HSU Voltage
2
Input Data
Process Monitor
3
Input Data
Purge Pressure
4
Input Data
Lens Position
5
Input Data
Process Monitor Temp
6
Input Data
Electronics Temp
7
Input Data
Collimator Temp
8
Input Data
Upper CG Temp
9
Input Data
Lens Temp
10
Input Data
Lower CG Temp
11
Input Data
Nozzle Temperature
12
Input Data
HSU Curve
13
Input Data
Aux Out Setting
14
Input Data
Focus Position
15
Input Data
Maximum Position
16
Input Data
Process Monitor Gain
0
Output Data
Digital Inputs
1
Output Data
Set Position
2
Output Data
Set HSU Curve
3
Output Data
Set Aux Out
4
Output Data
Set Focus Position
5
Output Data
Set Process Monitor Gain
 Digital Outputs
BIT 15
BIT 14
BIT 13
BIT 12
BIT 11
BIT 10
BIT 9
BIT 8
No
Comm.
Position
Error
Temperature
Fault
Purge Fault
Lens
Fault
HSU Fault
BIT 7
BIT 6
BIT 5
BIT 4
BIT 3
BIT 2
BIT 1
BIT 0
Reserved For
Future Use
Cal Ack.
Reserved for
Future Use
Lens in
Position
Lens at
Zero
TOUCH
READY
 Digital Inputs
BIT 15
BIT 14
BIT 13
BIT 12
BIT 11
BIT 10
BIT 9
BIT 8
Reserved For Future Use
Suppress Low
Purge Fault
BIT 7
BIT 6
BIT 5
BIT 4
BIT 3
BIT 2
BIT 1
BIT 0
Reserved For Future Use
Zero
Pressure
Move
Lens
Reset
CAL
ITEM
DESCRIPTION
Device
Anybus-IC EIP
Name
Exclusive Owner
Input
17 INT, Connection Point 100
Output
6 INT, Connection Point 150
