PLMNL0232 REV. H Effective Date: 01/14/19 58 FiberCUT
®
2D Operation Manual
 Other Descriptions
DATA
DESCRIPTION
HSU Voltage
The 12 bit ADC voltage output of the HSU.
Process Monitor
The 12 bit ADC voltage output of the process monitor.
Purge Pressure
The pressure (in millibars) within the purge path relative to the programmed ambient
pressure.
Lens Position
The commanded position of the lens in tenths of millimeters above the zero position.
Electronics Temp
The temperature of the height sensing electronics from 10.0-70.0 degrees Celsius.
Collimator Temp
The temperature of the collimator from 100-700 = 10.0-70.0 degrees Celsius.
Upper CG Temp
The temperature of the upper cover glass from 100-700 = 10.0-70.0 degrees Celsius.
Reports 999 if the drawer is not present.
Process Monitor
Temp
The temperature of the process monitor electronics from 100-850 = 10.0-85.0 degrees
Celsius.
Lens Temp
The temperature of the lens assembly from 100-700 = 10.0-70.0 degrees Celsius.
Lower CG Temp
The temperature of the lower cover glass 100-700 = 10.0-70.0 degrees Celsius.
Reports 999 if the drawer is not present.
Nozzle Temp
The temperature of the nozzle assembly from 100-700 = 10.0-70.0 degrees Celsius.
HSU Curve
The active HSU curve number from 1-31.
Aux Out Setting
The assigned function of the AUX OUT terminal.
Maximum Position
The highest allowable Lens Position value that the lens can be commanded to move to.
Process Monitor
Gain
The current level of gain on the process monitor output from 1-255.
A value of 0 indicates an error reading the current gain value.
Set Position
The Lens Position in tenths of millimeters above the zero position of the desired
movement. Movement will not occur until the Move Lens bit is activated.
Set HSU Curve
Changes the active curve of the HSU to the selected curve number and recalibrates.
Valid values are 1-31 as long as a curve is loaded in that location.
0 is considered an idle state and will retain the most recent setting.
Set Focus Position
Establishes the Lens Position in tenths of millimeters where focus is at the end of the tip.
Valid values are 1 to Maximum Position. 0 is considered an idle state and will retain the
most recent setting in memory.
Set Aux Out
The desired function of the AUX OUT terminal.
~ Values 1-4095 correspond linearly to fixed voltages of ~0-10V.
~ Values 9003-9011 output data corresponding to EtherNet/IP input words 3-11
respectively.
0 is considered an idle state and will retain the most recent setting in memory.
Any other value will set the output to 0V.
Set Process Monitor
Gain
The desired level of gain on the process monitor output from 1-255. Values outside this
range are ignored.
