PQIII Debugger | 11

1989-2021 Lauterbach GmbH

Configuration

System Overview

PODBUS Cable

PODPC

PODPAR Debug EPROM

PODETH Interface Simulator ...

(optional)

Debug Cable



CPU CLK  RESET

 INT

Target Connector

(600

EPROM only)



Target TS4 (400 only)

Basic configuration for the BDM Interface
