Lauterbach TRACE32 User Manual

PQIII Debugger | 42
©
1989-2021 Lauterbach GmbH
CPU specific MMU Commands
MMU.DUMP Page wise display of MMU translation table
Displays the contents of the CPU specific MMU translation table.
• If called without parameters, the complete table will be displayed.
• If the command is called with either an address range or an explicit address, table entries will
only be displayed if their logical address matches with the given parameter.
Format: MMU.DUMP <table> [<range> | <address> | <range> <root> |
<address> <root>]
MMU.<table>.dump (deprecated)
<table>: PageTable
KernelPageTable
TaskPageTable <task_magic> | <task_id> | <task_name> | <space_id>:0x0
<cpu_specific_tables>
<root> The <root> argument can be used to specify a page table base address
deviating from the default page table base address. This allows to display a
page table located anywhere in memory.
<range>
<address>
Limit the address range displayed to either an address range
or to addresses larger or equal to <address>.
For most table types, the arguments <range> or <address> can also be
used to select the translation table of a specific process if a space ID is
given.
PageTable Displays the entries of an MMU translation table.
•if <range> or <address> have a space ID: displays the translation
table of the specified process
• else, this command displays the table the CPU currently uses for
MMU translation.

Lauterbach TRACE32 Specifications

General

Operating System Support (Host)	Windows, Linux
Manufacturer	Lauterbach GmbH
Category	Debug and Trace Tool
Supported Architectures	ARM, Power Architecture, RISC-V, x86
Interface	JTAG, SWD, Nexus, Aurora
Features	Debugging, tracing, multicore debugging
Host Interface	USB, Ethernet
IDE Integration	Eclipse
Scripting Language	Practice
Power Measurement	Yes (requires specific PowerProbe hardware)
Trace Technology	Instruction Trace, Data Trace
License Type	Floating license, node-locked license available
Software Compatibility	Supports various compilers and toolchains
