Lauterbach TRACE32 User Manual

PQIII Debugger | 56
©
1989-2021 Lauterbach GmbH
JTAG Connector
Mechanical Description
JTAG Connector MPC85XX (COP)
This is a standard 16 pin double row (two rows of eight pins) connector (pin-to-pin spacing: 0.100 in.).
(Signals in brackets are not strong necessary for basic debugging, but its recommended to take in
consideration for future designs.)
Signal Pin Pin Signal
TDO 1 2 N/C
TDI 3 4 TRST-
(RUNSTOP-) 5 6 JTAG-VREF
TCK 7 8 (CHKSTPIN-)
TMS 9 10 N/C
(SRESET-) 11 12 GND
HRESET- 13 14 N/C (KEY PIN)
(CKSTOPOUT-) 15 16 GND

Lauterbach TRACE32 Specifications

General

Operating System Support (Host)	Windows, Linux
Manufacturer	Lauterbach GmbH
Category	Debug and Trace Tool
Supported Architectures	ARM, Power Architecture, RISC-V, x86
Interface	JTAG, SWD, Nexus, Aurora
Features	Debugging, tracing, multicore debugging
Host Interface	USB, Ethernet
IDE Integration	Eclipse
Scripting Language	Practice
Power Measurement	Yes (requires specific PowerProbe hardware)
Trace Technology	Instruction Trace, Data Trace
License Type	Floating license, node-locked license available
Software Compatibility	Supports various compilers and toolchains
