TapStates
SYStem.CONFIG.CHKSTPIN Control pin 8 of debug connector
Default: HIGH.
Controls the level of pin 8 (/CHKSTP_IN or /PRESENT) of the debug connector.
0 Exit2-DR
1 Exit1-DR
2 Shift-DR
3 Pause-DR
4 Select-IR-Scan
5 Update-DR
6 Capture-DR
7 Select-DR-Scan
8 Exit2-IR
9 Exit1-IR
10 Shift-IR
11 Pause-IR
12 Run-Test/Idle
13 Update-IR
14 Capture-IR
15 Test-Logic-Reset
Format: SYStem.CONFIG.CHKSTPIN LOW | HIIGH
