Lauterbach TRACE32 User Manual

PQIII Debugger | 6
©
1989-2021 Lauterbach GmbH
Warning
Signal Level
ESD Protection
NOTE: The debugger drives the output pins of the BDM/JTAG/COP connector with the
same level as detected on the VCCS pin. If the debug/trace I/O pins of the
processor are operating at e.g. 3.3 V, then VCCS should be connected to 3.3 V as
well.
See also System.up Errors.
WARNING: To prevent debugger and target from damage it is recommended to connect or
disconnect the Debug Cable only while the target power is OFF.
Recommendation for the software start:
1. Disconnect the Debug Cable from the target while the target power is
off.
2. Connect the host system, the TRACE32 hardware and the Debug
Cable.
3. Power ON the TRACE32 hardware.
4. Start the TRACE32 software to load the debugger firmware.
5. Connect the Debug Cable to the target.
6. Switch the target power ON.
7. Configure your debugger e.g. via a start-up script.
Power down:
1. Switch off the target power.
2. Disconnect the Debug Cable from the target.
3. Close the TRACE32 software.
4. Power OFF the TRACE32 hardware.

Lauterbach TRACE32 Specifications

General

Operating System Support (Host)	Windows, Linux
Manufacturer	Lauterbach GmbH
Category	Debug and Trace Tool
Supported Architectures	ARM, Power Architecture, RISC-V, x86
Interface	JTAG, SWD, Nexus, Aurora
Features	Debugging, tracing, multicore debugging
Host Interface	USB, Ethernet
IDE Integration	Eclipse
Scripting Language	Practice
Power Measurement	Yes (requires specific PowerProbe hardware)
Trace Technology	Instruction Trace, Data Trace
License Type	Floating license, node-locked license available
Software Compatibility	Supports various compilers and toolchains
